Planet LRP-101CE User Manual

12
Long
Reach
PoE
Interface
LRP Compatibility
LRP-101CE - 1-Port LRP
Extender
With power over coaxial
input
 LRP-101CH – 1-Port
LRP Injector
 LRP-822CS – 8-Port
LRP over Coax Switch
 LRP-1622CS – 16-Port
LRP over Coax Switch
LED Indicators
4 x LEDs
 PWR
 LRP LNK
 PoE IN
 LNK/ACT
4 x LEDs
 PWR
 LRP LNK
 PoE-in-use
 LNK/ACT
ESD Protection 2KV DC
EFT Protection 2KV ─
Enclosure Metal case
Installation Wall mount or DIN rail with optional kit
Dimensions (W x D x H) 94 x 70 x 26 mm
Weight 200g 375g
Power Requirements
 RJ45 PoE Input:
802.3at/af 48~56V
DC
 DC Input: 48~56V DC
BNC Power over Coaxial
Input: 44~56V DC
Standards Conformance
Standards Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Regulation Compliance FCC Part 15 Class A, CE
Environment
Temperature
Operating: -20~70 degrees C
Storage: -40~75 degrees C
