13
Humidity
Operating: 5~95% (Non-condensing)
Storage: 5~95% (Non-condensing)
* 1. Upload: LRP-101CE to LRP-101CH. Download: LRP-101CH to LRP-
101CE.
2. As there are various resistance values in the category of RG-59/U
or RG-6/U cable, the actual data rate will vary on the quality of
the copper wire and environment factors.
** Depending on what the DC/PoE Power Input and the length of
coaxial cable are.
1.4.2 LRP-101U-KIT Specications
Model LRP-101UH LRP-101UE
Hardware Specications
Ethernet
Interface
Copper
10/100BASE-TX RJ45
Auto-negotiation/ Auto-MDI/MDI-X
Power over
Ethernet
Standard
IEEE 802.3at/af PoE PD
(Powered Device)
IEEE 802.3at/af PoE
PSE (Power Source
Equipment)
PoE Input
Supports both Mid-Span
and End-Span PSE
Input Range: 48~56V
DC
PoE Output ─
48~56V DC, 600mA
max.
PoE Budget ─ Up to 25 watts
PoE Mode ─
End-span, RJ45 Pin
1/2(+), 3/6(-)
Data Rate 100/100Mbps
Cabling Cat5e or above
Maximum
Distance
100m
Maximum Frame
sizes
1522bytes
