Appendix A
A.1 Fiber Optic Cable Connection Parameters
The wiring details are shown below:
 Fiber Optic Patch Cables:
Standard Fiber Type Cable Specications
100BASE-FX Multi-mode 50/125μm or 62.5/125μm
100BASE-FX Single mode 9/125μm
100BASE-BX Multi-mode 50/125μm
1000BASE-SX Multi-mode 50/125μm or 62.5/125μm
1000BASE-LX Single mode 9/125μm
1000BASE-BX Single mode 9/125μm
