Planet PAX A77 User Manual

PAX A77 Setup and User Guide
weareplanet.com
12
8. Downloading software/rmware
1. To enter the IntegraTE_Pax menu, you will need to press and hold the ‘Planet' icon at the top of the
screen.
2. When “Please Enter Password” is displayed, enter password and press the green Enter button.
3. Then, select “Config/Configuration”.
4. Select “Update”.
5. Select “Firmware”.
6. The user must then verify that the information on the “Enter the TMS IP/DNS” and “Enter the TMS
port” screens match the information shown below.
7. Assuming the information matches, the user can proceed by tapping the green “Enter” button on
both screens.
*TMS IP depending on a use case. In production we have 194.7.129.134 for global use, and
065.216.73.214 as alternative in the US. The TMS Port is 8953 for Global and US use.
8. This will take you to the “Enter TMS TID” screen.
1
2
3
4
5
6
7

Planet PAX A77 Specifications

General

Brand	Planet
Model	PAX A77
Category	Touch terminals
Language	English
