3. Product Outlook
POE-151 / POE-152
There are two RJ-45 Twisted-Pair jack, one DC 48V Power socket and
two LED indicators.
48V DC
Ethernet
Power over Ethernet Injector
IEEE 802.3af
PoE
PWR
Ethernet+DC
PoE-IEEE 802.3af
Ready Power in-use
Figure 1: POE-151 / POE-152
POE-161
There are two RJ-45 Twisted-Pair jack, one DC 56V Power socket and
two LED indicators.
Figure 2: POE-161 Overview
4. LED Indication
LED Description
Power
Lights to indicate that the PoE Injector has power
from AC-DC adapter.
PoE In-use
Lights to indicate the PoE Injector is providing DC
in-line power.
