Planet POE-161 Manual

1-6
English
6.ProductSpecication
Product POE-151 POE-152 POE-161
HardwareSpecication
Interface
“Data” Input Port 1 x RJ-45 STP
“PoE
(Data+Power)”
Output Port
1 x RJ-45 STP
DC Input power
socket
1 x 48V DC 1 x 56V DC
LED Indicator
System: Power x 1 (Yellow)
PoE Port: PoE in Use x 1 (Green)
System:
Power x 1 (Green)
PoE Port:
PoE in Use x 1
(Green)
Network Cable UTPCat.5/5e/6,upto100m(328ft)
Data Rate 10/100Mbps 10/100/1000Mbps 10/100/1000Mbps
Dimension (W x D x H) 73 x 55 x 24 mm 73 x 55 x 24 mm 95 x 70 x 25 mm
Weight 50g 50g 83g
Unit Input Voltage DC48V,0.4A DC48V,0.4A DC56V,0.53A
Power Requirement 100-240VAC,50/60Hz
Power Consumption 15.4 Watts max. 15.4 Watts max. 30 Watts max.
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
IEEE 802.3at / af
Power over Ethernet
/ PSE
PoE Power Output DC 48V / 15.4 Watts DC 56V / 30 Watts
PoE Power supply Type Mid-Span End-Span Mid-Span
Power Pin Assignment 4/5(+),7/8(-) 1/2(+),3/6(-) 4/5(+),7/8(-)
Standards Conformance
IEEE 802.3 10Base-T Ethernet
  
IEEE 802.3u 100Base-TX
Fast Ethernet
  
IEEE 802.3ab 1000Base-T
Gigabit Ethernet
-
 
IEEE 802.3af Power over Ethernet
  
IEEE 802.3at Power over Ethernet - -

Regulation Compliance
FCCClassB,CE
mark
FCCClassB,CE
mark
FCCClassA,CE
mark
Environment
Operating Temperature 0 ~ 50 Degree C
Storage Temperature -10 ~ 70 Degree C
Humidity 5 ~ 90% (Non-condensing)
