Planet VTS-700WP User Manual

8
With 86 embedded box in the wall
A. Fix the wall bracket on the 86 embedded box with the two PM4*16mm
screws
PM4*16mm Screw*2
A
B
Step 2. Connect peripherals
If you need to connect other input and output devices, please connect to the
host through the cable
Step 3. Power on the device
If the powered device is working properly, align the slot with the rear side of
the panel with the pin on the wall bracket and slide the host down to complete
the installation.

Planet VTS-700WP Specifications

General

Brand	Planet
Model	VTS-700WP
Category	Intercom System
Language	English
