User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 23 -
Port definition
Object
Description
12V DC
12V DC port for the power adapter (DC-Jack 5.5 x 2.1 mm)
LED
The access point is on.
LAN
LAN port connecting to the network equipment.
PoE/WAN
LAN/WAN port with Power over Ethernet (PoE) IN
Reset
To restore to the factory default setting, press and hold the Reset Button for
about 5 seconds, and then release it.
WDAP-3000AX
 Dimensions: 231 x 80 x 295mm
 Weight: 2500 ±5GHz
 Apperance
