Quick Installation Guide
- 17 - PLANET Technology Corp.2024
3. After entering the password, the main screen appears as Figure 5-7
shows.
The following web screen is based on the firmware
version of February of 2024 or after.
1. When the following dialog box appears, please enter the default user
name “admin” and and password. Refer to following to determine
your initial login password.
Default IP Address: 192.168.0.100
Default User Name: admin
Default Password: sw + the last 6 characters of the MAC ID in
lowercase
2. Find the MAC ID on your device label. The default password is "sw" or
“mc” followed by the last six lowercase characters of the MAC ID.
Figure 5-3: Industrial Managed Switch MAC ID Label
