Command Guide
-241-
Switch# configure terminal
Switch (config)# mep 1 ais fr1s
4.2.124 mep <Instance> aps
Command:
mep <Instance> aps <prio> [ multi | uni ] { laps | { raps [ octet <octet> ] } }
mep Maintenance Entity Point
<Instance> The MEP instance number.
aps Automatic Protection Switching protocol
laps Linear Automatic Protection Switching protocol.
multi OAM PDU is transmitted with multicast MAC. Must me 'multi' in case of RAPS.
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database. Only possible in
case of LAPS.
raps Ring Automatic Protection Switching protocol.
octet Then last OCTET in the multicast MAC. Only possible in case of RAPS.
<Octet : uint> Last OCTET value
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database. Only possible in
case of LAPS.
Default:
None
Usage Guide:
To configure APS of MEP
Example:
To configure APS of MEP 1 as below table
Switch# configure terminal
Switch (config)# mep 1 aps 7 laps
