Rev 6.3.0 12.09.16PL Reference Manual
30
7
SET/EVNT/STRT Selection Summary
STRT Event starts when Value
to set
0 Solar panel voltage
(open circuit) > setting #
SOLV
1 Solar panel voltage
(open circuit) < setting #
SOLV
2 External voltage
VEXT * > setting
VEXT
3 External voltage
VEXT * < setting
VEXT
4 PB** is on and time > setting TIME
5 PB** is off and time > setting TIME
6 Not Used --
7 Not Used --
8 Repeat start at 10 min intervals
if time > setting
TIME
9 Repeat start at 30 min intervals
if time > setting
TIME
10 Repeat start at 1hr intervals if
time > setting
TIME
11 Repeat start at 2hr intervals if
time > setting
TIME
12 Time > setting (0.0-23.9) TIME
13 Not Used --
14 Repeat start at a set rate
(0-240 min)
RATE
15 Repeat start at a set rate
(0.0-24.0h)
RATE
#Note: After up to 6 min delay.
* Note: VEXT is the voltage on the B- sense input
(±8V relative to BAT- terminal). To configure the B-
sense input for this purpose, make BSET=2. This is
offset so that 80 on the VEXT setting screen is 0V.
It is scaled in 0.1V steps so that +2V is represented
by 100, or –3V is represented by 50.
**Note: “PB” means a push-button switch. If you
wish to use this option, you must wire a switch
or other trigger between the B- terminal (green
terminal block) and the BAT- terminal, and make
BSET = 2.
After setting the STRT value, a short-push will
move you to the setting, which goes with that
STRT value. For example, if you set STRT to “1”,
you will see SOLV. Whenever the solar panel
voltage drops below the value you set in SOLV,
the “event” will start.
Step 4
Use the STOP setting to tell the PL what signifies
the end of the “event”.
The STOP setting uses the following table:
SET/EVNT/STOP Selection Summary
STOP Event stops when Value to set
0 Solar panel open circuit voltage
> setting #
SOLV
1 Solar panel open circuit voltage
< setting #
SOLV
2 External voltage VEXT *
> setting
VEXT
3 External voltage VEXT *
< setting
VEXT
4 PB** off and time > setting TIME
5 PB** on and time > setting TIME
6 Not Used --
7 Not Used --
8 Repeat stop at 1 min intervals if
time > setting
TIME
9 Repeat stop at 3 min intervals if
time > setting
TIME
10 Repeat stop at 6 min intervals if
time > setting
TIME
11 Repeat stop at 12 min intervals
if time > setting
TIME
12 Time > setting (0.0-25.2) TIME
13 Not Used --
14 Stop after a set run time
(0-240min)
RUN
15 Stop after a set run time
(0.0-24.0h)
RUN
#Note: After up to 6min delay.
*Note: “VEXT” has the same meanings as in the
STRT table.
**Note: “PB” has the same meanings as in the
STRT table.
