Rev 6.3.0 12.09.16
PL Reference Manual
37
A
A.5 Thermal derating
The current rating of the PL must be reduced
at high ambient temperatures or the display
will darken until it is unreadable. The currents
indicate what can be done at the same time.
Because the limit is due to heating, there are
many combinations of charge and load current
which will produce the same heat level. This
table shows the limits of some combinations.
Air
temperature
around the PL
(°C)
Charge
Current Max
Load
Current Max
PL20 PL40 PL60 PL80 PL20 PL40 PL60 PL80
40°C 20 A 40A 60A 80A 20 A 7A 30A 40A
44 20 40 60 80 0 0 30 40
18 37 10
13 20
48 20 0 60 80 30 40
50 18 32 60 80 0 0 30 40
5 20
13 10
55 13 28 55 70
50 65
0 0 18 25
0 20 30 40
