Plasson IGBT Dimmer - Product Features; Protection Features

2 | Dimmer User Manual
Product Features
Main Features of Plasson LED Dimmer are as follows:
● Fully integrated digital control
system
● Input
Power Supply System: Automated
Voltage Detection and Switching
● 120VAC / 50HZ (or 60Hz) Allowable
voltage uctuation range: 90-
140VAC
● 220VAC / 50HZ (or 60Hz) Allowable
voltage uctuation range: 170-
260VAC
● Output
Two Zones: Zone1 and Zone2
Output voltage control range
● 0-120V/50Hz (or 60Hz)
● 0-220V/50Hz (or 60Hz)
Each Zone Output current range:
● 0-9A(in 110VAC system)
● 0-4.5A(in 220VAC system)
● Control input:
● Keypad Control in Manual Mode
● Analog Voltage Control of 0-10VDC
in Slave Mode
● Program Lighting Control in
Master Mode
● I GBT Control
● User interface:
● Keypad on front
● LCD display
● Status LEDs on front (normal,
alarm)
● No audible noise
● Protection
● Surge protection:
Lightning surge protection
● Overvoltage protection:
Dimmer will cut o output when
input voltage is over 160V or 260V
(in 110V/220V system).
● Short circuit protection:
Dimmer will cut o system
immediately when load current
ows over 30A
● Overload protection:
Dimmer will cut o output when
load current per Zone ows
over 9A
● Over Heat protection:
Dimmer will cut o output when
the temperature of dimmer is over
70° C (158° F)
● Allowable Loads:
Type: Incandescent bulbs, LED bulbs
