Plinius SA-100 - Page 18

18
220V-240V
OPERATION
110V-120V
OPERATION
W
H
I
T
E
BROWN
W
H
I
T
E
BLACK BROWN BLUE
W
H
I
T
E
B
R
O
W
N
W
H
I
T
E
BROWN BLUE BLUE
BLACK
BLACK
BLUE
BLACK
V
OLTAGE
C
ONFIGURATION
W
IRING
L
ABEL
With reference to the layout label attached to the bottom tray inside the amplifier, remove the ring
terminals on the transformer side of the connector block. Take care to ensure correct orientation of the
wires. Now reassemble your Plinius SA-100. If you experience any problems consult your PLINIUS
PLINIUSPLINIUS
PLINIUS
Dealer.
IMPORTANT: DOUBLE CHECK THE WIRE ORIENTATION BEFORE
REFITTING THE AMPLIFIER LID.
