PMC Pm25LV512/010
End View
5.00
4.80
Top View
Side View
4.00
3.80
6.20
5.80
1.75
1.35
0.25
0.10
0.51
0.33
1.27 BSC
0.25
0.19
1.27
0.40
45º
PACKAGE TYPE INFORMATION
8S
8-Pin JEDEC Small Outline Integrated Circuit (SOIC) Package (measure in millimeters)
