Standalone XBD Systems
For users not wishing to use the SoundAlign interface, a standalone XBD
system can be formed by connecting an Ethernet cable directly between
the RJ-45 connectors of the following speaker combinations:
– PMC6 and PMC8 SUB
– PMC6-2 and PMC8-2 SUB
– PMC8-2 and PMC8-2 SUB
When a standalone XBD link is formed both speakers adjust their crossover
to ensure optimum integration between the full-range and subwoofer
cabinets. Any parameter adjustments made using the rear-panel controls
of the full-range speaker will be applied simultaneously to the subwoofer.
Changes made using the subwoofer cabinet’s rear-panel controls will be
ignored, with the exception of changes to its input source.
Signal Input
(Analogue or Digital)
XBD Mode
ON
AES3 Input &
XBD Mode
ON
MASTER CABINET
PMC8 SUB or
PMC8-2 SUB
