Type Active 3-way neareld reference monitor with ATL
™
bass loading
Drive unit complement LF 2 x PMC 150mm (6”) studio 6 drivers
MF PMC55 55mm (2”) soft dome mid-range
HF PMC 27mm (1”) soft dome tweeter
Effective ATL
™
length
2m (6.6ft)
Frequency response 33Hz - 25kHz (- 3dB) (@1m full space, on-axis)
Sensitivity +4dBu input signal = 98dB SPL @ 1m
Max continuous SPL 109dB @1m
(Half space value calculated as +3dB from full space measurement.
Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
Max Peak SPL 121dB @1m
(Half space value calculated as +3dB from full space measurement.
Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
Directivity H +/-50 degrees V +60/-40 degrees (-6dB off axis @10kHz)
Input XLR switchable between analogue & digital AES3
Analogue input
- +20/+24dBu max. input level (selectable)
- 22K ohm input impedance
Digital input
- 16/24-bit AES3 signal, left, right or left + right
- 18 - 192kHz Sample Rate
- 110 ohm input impedance
Expansion card slot
- For future connectivity upgrades
Output XLR digital AES3 (xed 24-bit @ 96kHz)
Network RJ45 for use with PMC SoundAlign web interface
Features Level Trim (+/-10dB)
High-pass lter (20 - 200Hz, 12dB/Oct)
Delay (0 - 30mS)
Phase (normal or inverted)
LF & HF shelving lters (20Hz - 20kHz, +/- 10dB, Q 0.707)
Parametric EQ (5 bands, 20Hz - 20kHz, +/- 10dB)
User presets (3 + factory defaults)
Latency 2.4mS
Amplier power per channel LF 2 x 400Wrms MF 1 x 400Wrms HF 1 x 400Wrms
Mains 100 - 240VAC auto-switching, 50-60Hz (IEC C14)
Power consumption (idle) 50W
Power consumption (max) 1500W
Cabinet dimensions
H 400mm (15.7”) W 430mm (16.9”) D 372mm (14.6”)
Weight 21.3kg (47lbs) each
Available nishes Studio black
