Surround sound specic set up
5.1 Systems
The twenty5 series has been designed for perfect multi channel music or movie
playback and the following diagrams display the ideal layout for the speakers.
No doubt the constraints of room size and shape will vary the distances from
the listener to the speakers. Therefore use of the time alignment function of your
surround processor will be important.
The guidance given in the ‘Stereo set up’ and ‘Fine tuning for perfect
bass’ also apply to the set up of a surround system.
7.1 Systems
In a system capable of full 7.1 Dolby
®
Digital Surround EX
™
, DTS
®
ES
™
,
Blu-ray
™
or HD DVD
™
playback there will be two sets of surround speakers.
The rst pair should be positioned at 100º and the second set at 150º. (The centre is
considered 0º while directly to the rear of the room is 180º). See Ideal 7.1 surround
set up diagram.
Other Immersive Surround Formats
DTS:X™, Dolby Atmos™, Auro 3D® – we have models to suit every format.
With our vast array of product options it is easy to create a bespoke state-of-the-
art home cinema to take full advantage of the latest surround sound formats,
regardless of the number of channels or placement of the speakers. In addition to
the choices from the twenty5 series we produce in-wall and on-wall wafer models
and both active and passive subwoofers. See www.pmc-speakers.com for more
information.
