SERIEPMH–MANUALEDIUSOEMANUTENZIONE
PMHSERIES–OPERATIONANDMAINTENAINCEMANUAL
PMH.M001 14/09/2017
Rev.03‐2017 10/30
Posizionamento
Positioning
Orientazionedelmotore
Motororientation
Note
Notes
Alberoorizzontale
Porteadaltapressione
(A,B)laterali
Horizontalshaft
HighPressure
ports(A,B)onside
La linea di drenaggio deve essere
collegata alla porta posta più in
alto(T1)
Thecasedrainlinemustbealways
connected with the highest port
(T1)
Alberoorizzontale
Porteadaltapressione
(A,B)laterali
Horizontalshaft
HighPressure
ports(A,B)onside
La linea di drenaggio deve essere
collegata alla porta posta più in
alto(T2)
Thecasedrainlinemustbealways
connected with the highest port
(T2)
Alberoorizzontale
Porteadaltapressione
(A,B)sopraesotto
HorizontalshaftandHigh
Pressureports(A,B)on
topandonbottom
La linea di drenaggio deve essere
collegata alla porta posta più in
alto(T2)
Thecasedrainlinemustbealways
connected withthehighest
port(T1orT2)
