3 User manual
Technical specifications
Frequency range 26 - 28 MHz
Bandwidth 5 MHz
Polarization Vertical
Impedance 50 Ohm
Gain 5.5 dBi
Radiation Omnidirectional
Horizontal beam width 360º
Vertical beam width 20º
VSWR ≤1.5
Lightning protection Direct Grounding
Connector SO-239
Dimensions Ø36 x 6200 mm
Length 6200mm
Radiant material Copper
Antenna material Aluminum alloy
Operating temperature -26°C ~ +80°C
