76 - Manual de usuario
Alambrado
Zona 1
BELL_A Rosa Botón de timbre
BELL_B Rosa Botón de timbre
ALARM+ Rojo Conector de alarma
AC2 Negro ENTRADA AC
OPEN2 Amarillo Botón de salida
D_IN2 Marrón Contacto de puerta
ALARM2- Gris Alarma 2
NO2 Azul Relé 2 NO
COM2 Púrpura RELÉ 2 COM
NC2 Naranja RELÉ 2 NC
