1. Body
2. Front base
3. Rear base
4. Plastic nut
5. Power cable
PRODUCT OVERVIEW
1. Take out the fan body and the spare parts from the box. Put the front
base onto the rear base and join them together. (See Fig. 1)
2. Pass the power cable through the flute, then insert the fan body into the
base. (See Fig. 2)
3. Fix the fan body on the base with the plastic nut. (See Fig. 3)
ASSEMBLY INSTRUCTIONS
The outlet trough
Fig.1
Fig.3Fig.2
Note: All the illustrations in this
manual are for explanation purposes
only. If there are any discrepancies
between the real product and the
illustrations of the real product will
prevail.
