18
FEATURES AND CONTROLS
Console
Auxiliary Outlet
The 12-volt receptacle has spade
connections on the back that may be
used to power an auxiliary light or
other optional accessories or lights.
The connections are behind the con-
sole, under the hood.
Mode Button
The yellow button located near the
instrument cluster is used to toggle
through mode options available. See
pages 26-28.
Gear Selector
H: High Gear
L: Low Gear
N: Neutral
R: Reverse
P: Park
Low gear is the primary driving range for the RANGER. High gear is intended for use on
hard-packed surfaces with light loads. Whenever the vehicle is left unattended, always place
the transmission in PARK.
To change gears, stop the vehicle, and with the engine idling, move the lever to the desired
gear. Do not attempt to shift gears with engine speed above idle or while the vehicle is mov-
ing.
Tip: Maintaining shift linkage adjustment is important to assure proper transmission function. See your
dealer if you experience any shifting problems.
NOTICE: Shifting gears with the engine speed above idle or while the vehicle is moving could cause
transmission damage. Always shift when the vehicle is stationary and the engine is at idle.
Using Low Range
Always shift into low gear for any of the following conditions.
• Operating in rough terrain or over obstacles
• Loading the vehicle onto a trailer
• Towing heavy loads
