29
FEATURES AND CONTROLS
Instrument Cluster
Rider Information Center
Blink Code Descriptions
Blink
Code
Failure Description
-- No RPM Signal
21 Loss of Synchronization
45 Barometric Pressure Sensor: Circuit Low Input
46 Barometric Pressure Sensor: Circuit High Input
22 TPS: Open or Short Circuit to Ground
22 TPS: Short Circuit to Battery
23 RAM Error: Defective ECU
42 Engine Temp Sensor Circuit: Short to Ground
42 Engine Temp Sensor Circuit: Open or Short to Battery
51 Injector 1: Open Load
51 Injector 1: Short Circuit to Ground
51 Injector 1: Short Circuit to Battery
52 Injector 2: Open Load
52 Injector 2: Short Circuit to Ground
52 Injector 2: Short Circuit to Battery
53 Rear Differential: Open Load (RANGER 4X4 only)
53 Rear Differential: Short Circuit to Ground (RANGER 4X4 only)
53 Rear Differential: Short Circuit to Battery (RANGER 4X4 only)
54 Engine Temp Lamp: Open Load
54 Engine Temp Lamp: Short Circuit to Ground
54 Engine Temp Lamp: Short Circuit to Battery
55 Diag Lamp: Open Load
55 Diag Lamp: Short Circuit to Ground
55 Diag Lamp: Short Circuit to Battery
56 Pump Relay: Open Load
56 Pump Relay: Short Circuit to Ground
56 Pump Relay: Short Circuit to Battery
57 Reverse Beeper: Open Load
57 Reverse Beeper: Short Circuit to Ground
57 Reverse Beeper: Short Circuit to Battery
58 Cooling Fan: Open Load
58 Cooling Fan: Short Circuit to Ground
58 Cooling Fan: Short Circuit to Battery
41 Intake Air Temp Sensor: Open or Short Circuit to +Sensor Voltage
41 Intake Air Temp Sensor: Short Circuit to Ground
61 END
