103
MAINTENANCE
Seat Removal
1. Grasp one side of the seat
near the rear edge.
2. Pull upward abruptly to
disengage the under-seat
fasteners.
3. Remove the seat.
Side Panel/Footwell Removal
Remove the seat before removing a side panel. To remove a side panel
or footwell, remove the fasteners securing it to the frame. Lift the right
side panel upward while removing it to clear the shifter knob.
Plastic Rivet
Hex Head Screw
Plastic Rivet
Plastic Rivet
Torx Head
Screw
