HANDLEBAR COMPONENT FASTENER
TORQUES
COMPONENT TORQUE
DO NOT OVER-TIGHTEN
IMPORTANT: Moving a handlebar component without first loosening its screws/
set screws may cut grooves into the handlebar, making it difficult to secure the
component. Do not move a handlebar component without first loosening its
mounting screws/set screws.
Take care to avoid damaging hand warmer/brake switch wires when moving
components.
Left Hand Control/Brake Master Cylinder 24 in-lbs (2.7 Nm)
Upper / Lower Handlebar Clamps 7 ft-lbs (9.5 Nm)
Throttle Lever Block Set Screw 35 in-lbs (4 Nm)
Throttle Lever Block Cover Screws 6 in-lbs (0.7 Nm)
Auxiliary Engine Stop Switch Set Screw 12 in-lbs (1.4 Nm)
Hand Guard Mounts (if applicable) Hand-Tight
45
THE PERFECT FIT
