4. After achieving the desired belt deflection, tighten the jam nut to specification
while holding the adjuster screw stationary.
5. Turn the remaining adjuster screw inwards until it makes contact with the
spacer washer. Turn screw inwards slightly, and then tighten jam nut to
specification while holding the adjuster screw stationary.
TORQUE
Driven Clutch Adjustment Screw Jam Nuts
57.5-75 in-lbs (6.5-8.5 N·m)
DRIVE BELT REMOVAL
NOTICE
Do not attempt to remove the drive belt after operating in reverse. The
snowmobile must be stopped after forward motion to prevent damage to
components during belt removal. Rotate the driven clutch counter-clockwise 1/
4 turn by hand to ensure forward engagement before attempting to remove the
belt.
1. Stop the engine after operating in a forward motion.
2. Turn the ignition key off. Wait for the engine to come to a complete stop.
3. Lock the parking brake.
4. Remove the left side panel.
5. Rotate the driven clutch counter-clockwise 1/4 turn by hand to ensure
forward engagement.
6. Locate the L-wrench in the tool kit. Install the wrench into the open threaded
hole in the outer sheave of the clutch.
7. Turn the wrench clockwise until the sheaves open far enough to remove the
belt. If the wrench does not turn readily, rotate the driven clutch counter-
clockwise an additional 1/4 turn by hand and try again.
8. Remove the belt from the driven clutch.
91
MAINTENANCE
