TRACK TENSION DATA CHART
INDY (121) 10 lbs. (4.54 kg) 16 in. (40 cm)
ahead of rear
idler shaft
7/8-1 1/8 in. (2.2-
2.9 cm)
INDY EVO 10 lbs. (4.54 kg) 16 in. (40 cm)
ahead of rear
idler shaft
7/8-1 1/8 in. (2.2-
2.9 cm)
TIP
Tension adjustments should be made only after the track is warmed up and
limber.
1. Turn the engine off.
2. Lift the rear of the snowmobile and safely support it off the ground.
3. Place the recommended weight or downward pressure on the track at the
specified distance (see chart) ahead of the center of the rear idler wheel.
4. Measure at the point where the weight is hanging.
5. Check for specified slack between the wear surface of the track clip and the
plastic slider.
If the track needs adjustment:
6. Loosen the rear idler shaft bolt
e
.
94
MAINTENANCE
