8
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
8.81
7. Push the shock rod down into the shock body to expel
all of the nitrogen from the shock.
8. Remove the shock rod / bearing cap from the shock
body.
CAUTION
Residual nitrogen gas may exist inside shock. Wear
eye protection and use caution when removing shock
rod / bearing cap.
9. Remove the shock from the vise and pour shock oil
into an approved container. Place shock back into
vise.
10.Push the reservoir cap down, and remove the snap
ring.
11. Remove the reservoir cap from the reservoir.
12.Remove the bleed screw and O-ring from the internal
floating piston (IFP).
13.Use the T-handle tool to remove the IFP.
14.Remove the shock from the vise and pour residual
shock oil into an approved container.
STEERING / SUSPENSIONS
