SPECIFICATIONS
ACE 150 EFI
Maximum Rider Weight 81 kg (180 lbs.)
Maximum Weight Capacity 104 kg (230 lbs.)
Gross Vehicle Weight 364 kg (802 lbs.)
Dry Weight 252 kg (556 lbs.)
Fuel Capacity 9.5 ltr (2.5 gal.)
Engine Oil Capacity 1050 ml (35.5 oz.)
Transmission Oil Capacity 750 ml (25 oz.)
Overall Length 216 cm (85 in.)
Overall Width 122 cm (48 in.)
Overall Height 147.3 cm (58 in.)
Wheelbase 165 cm (65 in.)
Ground Clearance 22.9 cm (9 in.)
Engine Type 4-Stroke
Displacement 150 cc
Cooling Air + Oil
Bore x Stroke 57.4 mm x 57.8 mm
Alternator Output 180 watts
Compression Ratio 9.5:1
Starting System Electric
Fuel System Electronic fuel injection
Throttle Body Size 32 mm
Ignition System Electronic Control Unit
Ignition Timing Timing non-adjustable, ECU controlled
Spark Plug / Gap NGK CR7HSA / 0.6-0.7 mm
Front Suspension Dual A-arm w/13 cm (5.1 in.) travel
99
SPECIFICATIONS
