OIL CHANGE
1. Position the vehicle on a level surface. Set the parking brake.
2. Clean the area around the pre-filter plug.
3. Start the engine. Allow it to idle for two to three minutes.
4. Stop the engine.
CAUTION
Hot oil can cause burns to skin. Do not allow hot oil to contact skin.
5. Remove the 4 nuts/bolts holding the lower chain guard in place. Remove the
lower chain guard to avoid collecting oil as it drains.
6. Place a drain pan under the engine crankcase.
7. Remove the pre-filter plug. Allow the oil to drain completely.
8. Wash the oil pre-filter screen with solvent to remove debris. Allow the screen
to air dry.
9. The external oil filter is located behind the seat on the right-hand side of the
rear swingarm. The screw on the oil filter should be replaced when oil is
changed. With the oil drained from the crankcase, unscrew the oil filter and
replace with a new one. Ensure that the oil filter gasket is properly seated,
lubricated with oil and in good condition. Do not over tighten the oil filter.
10.Clean the pre-filter plug. Install a new sealing washer on the plug. The
sealing surfaces on the plug and crankcase should be clean and free of
burrs, nicks or scratches.
11. Reassemble the pre-filter screen and spring to the pre-filter plug.
12.Reinstall the pre-filter drain plug. Torque to 15 Nm (11 ft-lbs).
13.Reinstall the lower chain guard.
14.Remove the dipstick. Add 1050 ml (35.5 oz.) of the recommended oil. Do not
overfill. See the Specifications section for capacities.
15.Reinstall the dipstick.
16.Start the engine. Allow it to idle for one to two minutes.
17.Stop the engine and inspect for leaks.
18.Check the oil level. Add oil as needed to bring the level to the upper mark on
the dipstick.
19.Dispose of used oil properly.
66
MAINTENANCE
