Prepare the Conduit
Run separate conduits for each lens location. Use only sweep ells or heat-bent PVC, not
standard 90° plumbing fittings. Center the fiber optic conduits where the installation base will
be placed.
Remove the cover and separate the chassis assembly from the installation base. Using the
handles, lift the chassis off the base and place it in a safe location until ready to complete
electrical connections.
Cut the conduit so it protrudes 1/3 of the way into the installation base.
Guide the electrical conduit through the small hole in the installation base until it extends
1" to 4" above the base.
www.polarispool.com
Installation Instructions
1
