102
MAINTENANCE AND LUBRICATION
Adjustments
Wheel Installation
1. With the transmission in
park and t he parking
brake locked, place the
wheel on the wheel hub
with the valve stem
toward the outside and
rotation arrows on the tire
pointing toward forward
rotation.
2. Install the wheel nuts and finger
tighten.
3. Lower the vehicle to the ground.
4. Torque the wheel nuts according to the wheel nut torque
specifications chart.
NOTE: All nuts that have a cotter pin installed must be serviced by an
authorized Polaris dealer.
Wheel Nut To rque Specifications
Check the wheel nut torques occasionally and when they’ve been
loosened for maintenance service.
Bolt Size Specification
Front 3/8″ 20 ft. lbs. (27 Nm)
Rear 3/8″ 20 ft. lbs. (27 Nm)
