126
SPECIFICATIONS
ATP 330 4x4
Gross Vehicle Weight 1300 lbs./590 kg
Fuel Capacity 3.25 gal./12.3 l
Hitch Towing Rating 1000 lbs./454 kg
Unbraked Trailer Towing Capacity* 1585 lbs./719 kg
Hitch Tongue Capacity 100 lbs./45.4 kg (rear box capacity and
tongue weight not to exceed 250 lbs./113 kg)
Front Rack & Compartment Capacity 90 lbs./40.8 kg
Rear Box Capacity 250 lbs./113 kg
Overall Length 91 in./231 cm
Overall Width 46 in./116.8 cm
Overall Height 46 in./116.8 cm
Wheelbase 56 in./142 cm
Ground Clearance 6.5 in./16.5 cm
Dry Weight 719 lbs./326 kg
Minimum Turning Radius 75 in./190.5 cm unloaded
Engine Oil Capacity 1.9 qts./1.8 l
Engine ES320PFE101
Displacement 329 cc
Bore x Stroke 78.5 x 68
Pilot Jet 42.5
Main Jet 122.5
Needle Jet P-0M
Jet Needle 4HB48-2 (2nd clip)
Pilot Screw 2 Turns Out
Alternator Output 200 w @ 5000 rpm
Compression Ratio 9.2:1 Full Stroke
Starting System Electric
Carburetor 1/BST34 (CV Type)
Ignition System CDI (Analog)
Ignition Timing 30°±2° @ 5000 RPM
SparkPlug/Gap NGK BKR6E / .036 in/0.9 mm
Lubrication System Wet Sump
Driving System Type PVT
* Based on EU Directive 76/432/EC
