128
SPECIFICATIONS
ATP 500 4x4
Gross Vehicle Weight 1500 lbs./680 kg
Fuel Capacity 3.25 gal./12.3 l
Towing Rating 1225 lbs./556 kg
Unbraked Trailer Towing Capacity* 1847 lbs./838 kg
Hitch Tongue Capacity 120 lbs./54.4 kg (Rear box capacity and
tongue weight not to exceed 400 lbs./181 kg)
Front Rack & Compartment Capacity 90 lbs./40.8 kg
Rear Box Capacity 400 lbs./181 kg
Overall Length 91 in./231 cm
Overall W idth 46 in./116.8 cm
Overall Height 47 in./119.4 cm
Wheelbase 56 in./142.2 cm
Ground Clearance 7.0 in./17.8 cm
Dry Weight 738 lbs./335 kg
Minimum Turning Radius 75 in./190.5 cm unloaded
Engine Oil Capacity 2qts./1.9l
Coolant Capacity 3.2 qts./3.02 l
Engine EH500PLE200
Displacement 499 cc
Bore x Stroke 92x75
Pilot Jet 40
Main Jet 155
Needle Jet Y-0
Jet Needle 6H25-94-3
Pilot Screw 2 Turns Out
Alternator Output 250 w
Compression Ratio 10.2:1 Full Stroke
Starting System Electric
Carburetor 1/BST34
Ignition System DC CDI
Ignition Timing 30°±1.5° @ 3500 RPM
SparkPlug/Gap BKR5E / .028 in/0.7 mm
Lubrication System Dry Sump
Driving System Type PVT
* Based on EU Directive 76/432/EC
