SPECIFICATIONS
ATP 500 4X4
Lubrication System Dry Sump
Driving System Type PVT
Shift Type Side Lever (H/L/N/R/P)
Gear Reduction - Low 8.66:1
Gear Reduction - Reverse 5.12:1
Gear Reductio n - High 3.52:1
Drive Ratio - Front 3.7:1
Drive Ratio - Final 3.08:1
Tire Size - Front 25x8-12
Tire Size - Rear 25x11-12
Tire Pressure- Front 5psi
Tire Pressure- Rear 5psi
Front/Rear Brakes Hydraulic Disc
Auxiliary Brake Hydraulic Disc
Parking Brake Hydraulic lock, all wheel
Headlight Single beam/60 watt
Grill - 2 single beam/27 watt
Taillights Two 12v/3.8 watt
Brake Light Two 12.8v/37 watt
Instrument Cluster LCD
Jetting (ATP 500)
Altitude AMBIENT
TEMPERATURE
Below 40° F
Below 5° C
+40°Fand above
+5°C to & above
Meters
(Feet)
0-1800
(0-6000)
160 155
1800-3700
(6000-12000)
152.5 147.5
Clutching (ATP 500)
Altitude Shift
W eight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix*
Meters
(Feet)
0-1800
(0-6000)
10 BH
PN 5630711
Blue/Green
PN 7041157
White/Yellow
PN 7041635
EBS*
5132751
1800-3700
(6000-12000)
10 RH
PN 5630709
Blue/Green
PN 7041157
White/Yellow
PN 7041635
EBS*
5132751
EBS models require no helix / spring adjustment
