Polaris ATV 2002

164
MAINTENANCE AND LUBRICATION
Side Panel Removal (Gen IV Models)
Side panel removal may be difficult until the locking tabs and receivers
have been snapped and unsnapped a few times.
1. Remove seat. Grasp
rear of side panel near
rear cab. With a quick
and firm motion, pull
the panel forward and
outward to disengage
the two rear tabs.
2. Place hand on top of
side panel behind the
fuel tank. With a quick
and firm motion, push
down on the side panel
to disengage the top
rear two tabs. Then
pulluponsidepanelto
disengage front upper
and lower tab.
3. To reinstall side panel,
align panel tabs with
slots on front cab.
Push panel upward and
forward until tabs lock.
Bend rear of side panel
and insert the two tabs
into the rear cab.
1
3
2
