2. Install brake line and torque the banjo bolt (Item 1) to
the proper torque specification.
3. Install the pad adjustment screw (Item 2) and turn
until stationary pad contacts disc, then back off 1/2
turn.
4. Perform brake bleeding procedure as outlined earlier
in this chapter.
5. Install wheel and torque wheel nuts to specification
(see Chapter 2).
NOTICE
If new brake pads are installed, brake burnishing is
required. SeeBrake Burnishing Procedure page 10.11.
BRAKE SYSTEM
