Page #92 background image
90
SPECIFICATIONS
RANGER 570
Maximum Weight Capacity
(includes weight of operator, passenger,
cargo, accessories)
454 kg
Dry Weight 470 kg (2X4)
488 kg (4X4)
550 kg (ZUG Models)
Vehicle Seating Capacity 2
Test GVW - Rollover Protection System
(ROPS)
1247 kg per OSHA 29 CFR 1928.53
Fuel Capacity 33.3 l
Engine Oil Capacity 1.9 l
Coolant Capacity 3.5 l
Overall Length 279.4 cm
Overall Width 147.3 cm
Overall Height 185 cm
Wheelbase 185 cm
Cargo Box Dimensions (Inside) 81x107x29 cm
Ground Clearance 25.4 cm
Min. Turning Radius 381 cm
Towing Capacity 680.4 kg
Hitch Tongue Capacity 68 kg
Max. Cargo Box Load 227 kg
Engine Dual overhead cam, 4 valve 4 stroke single cylinder
Displacement 567 cc
Bore x Stroke (mm) 99mm x 73.6mm
Alternator Output 460 W @ 3000 RPM
Compression Ratio 10:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition Timing ECU Controlled
32° +/- 2° @ 5000 RPM
Spark Plug NGK MR7F / 0.7-0.9 mm
Lubrication System Wet Sump
Cooling Liquid
Front Suspension McPherson Strut w/20.3 cm of travel
Rear Suspension Independent, 23 cm of travel
Throttle Body Size 42 mm
Ignition System Digital CDI
