ALL WHEEL DRIVE/ACTIVE DESCENT CONTROL
SYSTEM
ADC models are equipped with a drive mode switch that controls the AWD
system. The AWD/ADC Drive Mode switch controls AWD through drive mode
options which display in the information center of the gauge.
DRIVE MODE OPERATION
Use the drive mode switch to engage AWD (4X4), ADC 4X4, TURF mode or
2X4. The vehicle automatically engages 4X4 when operating in reverse if the
drive mode is set to either AWD (4X4) or ADC 4X4.
• Always operate in low gear and engage ADC 4X4 when transporting heavy
loads and/or when towing.
• Always operate in low gear and engage ADC 4X4 before ascending or
descending a hill.
WARNING
Operate in TURF mode only as needed to protect smooth, level surfaces from
tire damage. DO NOT operate in TURF mode when climbing or descending
hills, when sidehilling, or when operating on uneven, loose, or slippery terrain
such as sand, gravel, ice, snow, obstacles, and water crossings.
DRIVE MODE SWITCH
Press and release the top of the switch
q
to toggle through the drive mode
options, which display in the
information center of the gauge for
several seconds.
Press and release the bottom of the
switch
w
to toggle to a previous
option.
When the switch is released, the drive mode displayed in the information center
is the active drive mode.
NOTICE
Switching to 4X4 or ADC 4X4 while the rear wheels are spinning may cause
severe drive shaft and gearcase damage. Always switch to 4X4 or ADC 4X4
while the rear wheels have traction or are at rest.
68
OPERATION
