9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual

5.21

20.Connect the fuel line to the fuel pump outlet.

NOTICE

Be sure to engage the retainer on fuel line until it snaps

into place. Pull on fuel line lightly to confirm connection.

21.Connect the fuel pump electrical harness.

22.Connect battery.

23.Install the seat.

24.Test the fuel pump by turning on the key and listening

for the pump to activate. Cycle the key several times

to prime the system and check for leaks.

FUEL SYSTEM
