9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
1.85
SPN COMPONENT
FMI CONDITION CODE
520305
Throttle Body Control - Requested
Throttle Angle Not Plausible
31 Condition Exists P1530
520306 ECU ADC Fault - No Load
31 Condition Exists P1531
520307
ECU ADC Fault - Voltage
31 Condition Exists P1532
520308
Accelerator Sensor Sync Fault -
Sensor Diff Exceeds Limit
31 Condition Exists P1533
520309 ECU Fault - ICO
31 Condition Exists P1534
520311
ECU Fault - Hardware Disruption
31 Condition Exists P1537
520331 Knock Sensor Positive Line
3 Voltage Above Normal, Or Shorted To High Source P1327
4 Voltage Below Normal, Or Shorted To Low Source P1328
520332
Knock Sensor Negative Line
3 Voltage Above Normal, Or Shorted To High Source P132A
4 Voltage Below Normal, Or Shorted To Low Source P132B
520341
Wastegate Solenoid Driver
3 Voltage Above Normal, Or Shorted To High Source P0243
4 Voltage Below Normal, Or Shorted To Low Source P0246
5 Current Below Normal Or Open Circuit P0245
520342 Idle Fuel Correction Bank 1
15 Data Valid But Above Normal Operating Range - Least Severe Level P116C
520343 Idle Fuel Correction Bank 2
15 Data Valid But Above Normal Operating Range - Least Severe Level P116E
17 Data Valid But Below Normal Operating Range - Least Severe Level P116F
520344
Adaptive Fuel Correction Bank 1
15 Data Valid But Above Normal Operating Range - Least Severe Level P0170
17 Data Valid But Below Normal Operating Range - Least Severe Level P1170
520376
Internal fault - Chassis Output
Disabled
31 Condition Exists P1618
520381
Non Functional Application SW
Installed
31 Condition Exists C1681
520496
Intercooler Pump Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P107D
4 Voltage Below Normal, Or Shorted To Low Source P107C
5 Current Below Normal Or Open Circuit P107E
520498 Stator
4 Voltage Below Normal, Or Shorted To Low Source P1510
5 Current Below Normal Or Open Circuit P1511
520513 Motor Controller Encoder
2 Data Erratic, Intermittent Or Incorrect P1140 / P1368
31 Condition Exists P1141 / P1369
520514
Motor Controller Temperature
Sensor
3 Voltage Above Normal, Or Shorted To High Source P1142 / P1165
4 Voltage Below Normal, Or Shorted To Low Source P1143 / P1166
31 Condition Exists P1144 / P1167
520515
Electric Motor Temperature
0 Data Valid But Above Normal Operational Range - Most Severe Level P1145 / P1168
4 Voltage Below Normal, Or Shorted To Low Source P1B0D / P1169
520516
Motor Controller Temperature
0 Data Valid But Above Normal Operational Range - Most Severe Level P1146 / P116A
520517 Motor Controller
3 Voltage Above Normal, Or Shorted To High Source P1147 / P1184
6 Current Above Normal Or Grounded Circuit P1148 / P1185
12 Bad Intelligent Device Or Component P1149 / P1186
19 Received Network Data In Error P1150 / P1187
520518 Motor Controller Contactor
5 Current Below Normal Or Open Circuit P1151 / P1177
6 Current Above Normal Or Grounded Circuit P1152 / P1178
520519
Motor Controller Speed Sensor
31 Condition Exists P1153 / P116B
520520 BMC CAN Communication
31 Condition Exists P0754
520522
Display Relay
5 Current Below Normal Or Open Circuit P3038
524067 Drive Mode Select Switch
2 Data Erratic, Intermittent Or Incorrect P153C
3 Voltage Above Normal, Or Shorted To High Source P153A
4 Voltage Below Normal, Or Shorted To Low Source P153B
524070
Operator Presence Switch
3 Voltage Above Normal, Or Shorted To High Source P251C
