SPECIFICATIONS
RANGER 570 FULL-SIZE SPORT
Maximum Weight
Capacity (includes weight
of operator, passenger,
cargo, accessories)
1500 lbs. (680.4 kg) (4X4)
1300 lbs. (590 kg) (4X4 sold in California)
Dry Weight 1140 lbs. (517 kg)
Test GVW - Rollover
Protection System
(ROPS)
2850 lbs. (1292 kg) per OSHA® 29 CFR
1928.53
Fuel Capacity 8.8 gal. (33.3 L)
Engine Oil Capacity 2 qts. (1.9 L) with filter
Coolant Capacity 5 qts. (4.75 L)
Overall Length 114 in. (290 cm)
Overall Width 60 in. (152.4 cm)
Overall Height 74 in. (188 cm)
Wheelbase 79.5 in. (202 cm)
Cargo Box Dimensions
(Inside)
36.5x54x11.5 in. (93x173x29 cm)
Ground Clearance 10.5 in. (26.7 cm)
Min. Turning Radius 192 in. (487.7 cm)
Towing Capacity 1500 lbs. (680 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load 800 lbs. (363 kg)
600 lbs. (272 kg) (Models sold in California)
Engine Dual overhead cam, 4 valve 4 stroke single
cylinder.
Displacement 567 cc
Bore x Stroke (mm) 99mm x 73.6mm
Alternator Output 560 W @ 3000 RPM
131
SPECIFICATIONS
