FOOT PEDALS
BRAKE PEDAL
Depress the brake pedal
q
to slow or stop the vehicle. Apply the brakes while
starting the engine.
When the brake pedal is depressed, the brake light comes on. Check the brake
light before each ride.
1. Turn the ignition switch to the ON position.
2. Apply the brakes. The brake light should come on after about 10 mm (0.4 in.)
of pedal travel.
THROTTLE PEDAL
Push the throttle pedal
w
down to increase engine speed. Spring pressure
returns the pedal to the rest position when released. Always check that the
throttle pedal returns normally before starting the engine.
This vehicle is equipped with an automatic throttle release switch, which is
designed to reduce the risk of a frozen or stuck throttle. If the throttle cable
should stick in an open position when the operator releases the throttle pedal,
engine speed will be limited, and power to the rear wheels will be reduced.
49
FEATURES AND CONTROLS
