94
SPECIFICATIONS
RANGER 800 EFI/EPS
Maximum Weight Capacity 1500 lbs. (681 kg) (including operator, passenger, cargo, accessories)
1100 lbs. (499 kg) (Models sold in California)
Dry Weight 1237 lbs. (561 kg)
Test GVW - Rollover Protection
System (ROPS)
2940 lbs. (1333.5 kg) per OSHA 29 CFR 1928.53
Fuel Capacity 8.8 gal. (33.3 l)
Engine Oil Capacity 1.9 qts. (1.8 l)
Coolant Capacity 3.25 qts. (3 l)
Towing Capacity 2000 lbs. (907 kg)
Hitch Tongue Capacity 150 lbs. (68 kg)
Max. Cargo Box Load* 1000 lbs. (454 kg)
600 lbs. (272 kg) (Models sold in California)
Overall Length 114 in. (289.6 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 76 in. (193 cm)
Wheelbase 76 in. (193 cm)
Cargo Box Dimensions (Inside) 36.5 x 54 x 11.5 in. (93 x 137 x 29 cm)
Ground Clearance 11.5 in. (29.2 cm)
Min. Turning Radius 158 in. (401 cm)
Engine 4 valve 4 stroke twin cylinder with counter balance
Displacement 760 cc
Bore x Stroke 80 x 76.5
Alternator Output 500 W @ 3000 RPM
Compression Ratio 10.0:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition System Bosch EFI ECU Controlled
Spark Plug / Gap RC7YC3 /.035 in. (0.9 mm)
Front Suspension Dual A-arm w/9.6 in. (24.4 cm) of travel
Rear Suspension Independent w/9 in. (23 cm) of travel
Lubrication System Pressurized Wet Sump
