Max. Cargo Box Load 500 lbs. (226 kg)
Engine Dual overhead cam, 4 valve 4 stroke single
cylinder.
Displacement 567 cc (570)
Bore x Stroke (mm) 99mm x 73.6mm (570)
Alternator Output 660 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic Fuel Injection
Ignition Timing ECU Controlled
32° +/- 2° @ 5000 RPM
Spark Plug NGK® MR7F / .031” (0.7-0.8 mm)
Lubrication System Wet Sump
Cooling Liquid
Front Suspension MacPherson Ride® Strut w/9 in. (22.9 cm) of
travel
Rear Suspension Dual A-Arm, IRS w/10 in. (25.4 cm) of travel
Throttle Body Size 42 mm (570)
Ignition System Digital CDI
Driving System Type PVT, 4-wheel independent shaft, lockable
differential
Shift Type Single Lever (H/L/N/R/P)
Gear Reduction - Low 28.84:1
Gear Reduction - Reverse 25.82:1
Gear Reduction - High 13.57:1
Drive Ratio - Front 3.818:1
Tire Size - Front 25 x 8 x 12
Tire Size - Rear 25 x 10 x 12
156
SPECIFICATIONS
