14.Make sure the transmission is in PARK. Apply the brakes.
15.Start the engine. Allow it to idle for one to two minutes.
16.Stop the engine. Inspect for leaks.
17.Re-check the oil level on the dipstick and add oil as necessary to bring the
level to the upper mark on the dipstick.
18.Dispose of used filter and oil properly.
GEARCASES
GEARCASE SPECIFICATION CHART
GEARCASE LUBRICANT CAPACITY
FILL PLUG
TORQUE
DRAIN PLUG/
LEVEL
CHECK PLUG
TORQUE
Main
Gearcase
(Transmission)
AGL Gearcase
Lubricant &
Transmission
Fluid
1200 ml
(40.6 oz.)
14 ft-lbs (19
Nm)
14 ft-lbs (19
Nm)
Front
Gearcase
Demand Drive
Fluid
200 ml
(6.8 oz.)
12 ft-lbs (16
Nm)
12 ft-lbs (16
Nm)
109
MAINTENANCE
