FRONT GEARCASE / CENTRALIZED HILLIARD
CENTRALIZED HILLIARD ASSEMBLY VIEW
q
O-Ring
k
Roll Cage
w
O-Ring
1(
Hub / Race Assembly
e
Dowel Pin
2)
Hub Sub-Assembly (Female)
r
Vent Hose Fitting
2!
Hub Sub-Assembly (Male)
t
Ball Bearing
2@
Rollers
y
Ball Bearing (Double Row)
2#
Torsion Spring
u
Bushing
2$
H-Clip Spring
i
Bushing
2^
Nylon Spacer
o
Oil Seal
2&
Backlash Spacer
a
Oil Seal
2*
Ring Gear Spacer
s
Retaining Ring, Internal
2(
Torsion Spring Retainer
d
Retaining Ring
3)
Pinion Gear
f
Cover Screws, M6 (T30 Torx)
3!
Armature Plate
g
Cover Plate Assembly
3@
AWD Coil
h
Gearcase Housing
3%
Fill Plug
j
Clutch Housing (Ring Gear)
3^
Drain Plug, Magnetic
