FACTORY DEFAULT PRELOAD SETTINGS
FACTORY DEFAULT PRELOAD SETTINGS
RZR XP 1000
Front
1.49 inches (38 mm)
Rear
7.75 inches (197 mm)
RZR XP 4 1000
Front
2.04 inches (51 mm)
Rear
5.83 inches (148 mm)
RZR XP 1000 Trails
and Rocks Edition
Front
1.30 inches (33 mm)
Rear
7.65 inches (194 mm)
Follow these guidelines if you make adjustments to this suspension.
• Always return the suspension to the factory setting after the load is removed
from the vehicle. The increased suspension height will negatively impact
vehicle stability when operating without a load.
• Always apply the same adjustment setting to all four wheels.
Do not increase the spring preload by more than one inch (25.4 mm) over the
factory setting.
160
MAINTENANCE
