RZR XP 4 1000
Gross Vehicle Weight RZR XP 4 1000: 2640 lbs. (1200 kg)
Dry Weight* RZR XP 4 1000: 1671 lbs. (758 kg)
RZR XP 4 1000 with Ride Command: 1683
lbs. (763 kg)
*Dry weight is also listed on the Certificate of Origin for your vehicle in the
Shipping Weight field. The dry weight is estimated based on the
manufactured weight of the vehicle minus any serviceable fluids and may also
exclude the weight of factory installed accessories not essential to the
vehicle’s basic operation as outlined in the ANSI®/ROHVA® 1-2016 standard.
Test GVW - Rollover
Protection System (ROPS)
2760 lbs. (1247 kg) per OSHA® 29 CFR
1928.53
Rear Cargo Box Capacity 300 lbs. (136 kg)
Maximum Weight Capacity
(Payload)
900 lbs. (408 kg)
(including riders, cargo and accessories)
Fuel Capacity 9.5 gal. (36 l)
Engine Oil Capacity 2.5 qts. (2.4 l)
Coolant Capacity 6.08 qts. (5.75 l)
Demand Drive Fluid Capacity 8.5 oz. (251 ml)
Transmission Oil Capacity 44 oz. (1300 ml)
Overall Length/Width/Height 146/64/73.75 in. (370.8/162.5/187.3 cm)
Wheelbase 117 in. (297.2 cm)
Ground Clearance 13.5 in. (34.3 cm)
Engine 4-Stroke DOHC Twin Cylinder
Displacement 999 cc
Bore x Stroke 93mm x 73.5mm
Alternator Output 560 W @ 3000 RPM
Compression Ratio 11.0:1
Starting System Electric
179
SPECIFICATIONS
